Gen3 Image Intensifier Tube FOM2300+
High-sensitivity image intensifier tube with S25R photocathode and FOM 2300+, responding from visible light to 1100nm near-infrared.
| FOM | 2300+ |
|---|---|
| Limiting Resolution (lp/mm) | 72+ |
| Signal-to-Noise Ratio | 30+ |
| Gain | 10000-20000 |
| Max. Output Brightness (cd/m²) | 4-10 |
| Halo | 0.8 (Maximum) |
| Cathode Sensitivity @2856K (μA/lm) | 1200+ |
| Effective Diameter | 18mm |
| Power Type | Auto-gating |
Product Details
This tube adopts the latest S25R photocathode manufacturing technology and a high-resolution microchannel plate. Its photocathode sensitivity exceeds 1200μA/lm@2856K, with high sensitivity in the near-infrared band.
- Higher FOM for better target detection, recognition and identification
- Small halo, low power consumption, fast response and high reliability
- Response band from visible light to near-infrared (1100nm)
- Electromagnetic compatibility, external brightness / gain adjustment
